Characteristics of the CHIROPRO + TRIOPACK Surgery Surgical Drill MAINTENANCE

- TOTAL ACCURACY

Thanks to a high precision electronic system, the torque selected on the console corresponds exactly to the torque obtained at the output of the instrument.

No calibration is required thanks to the minimum deviation of the motor torque at the output (+/-5 %). This makes the third generation of the Chiropro potentially the most precise implantology system on the market.

Automatic adjustment of the torque according to the bone strength during implant placement, prevents blockage of the drill.

The value of the maximum applied torque remains visible on the display for better documentation.

- HandpiecePM 1:2 The high rotational speed reduces the cutting time by 70% (12 seconds for a complete tooth split), while considerably reducing the force required. The PM 1:2 is also equipped with a Bur Guard that prevents liquid from infiltrating both the handpiece and the motor. This significantly reduces the risk of overheating and premature handpiece failure.

- The new CA 1:2.5 L Micro-Series is the ultimate contra-angle handpiece for surgery and periodontics. Thanks to its multiplication ratio, the CA 1:2.5 L Micro-Series can be used in numerous clinical applications: wisdom tooth removal, apicoectomies, crown lengthening and root extraction.

- Pre-programmed surgical protocols, the implant procedure can be performed without complications.the predefined sequences can support the protocols of all implant manufacturers and any bone condition.the surgical sequence can be customized and saved on the machine to save time.

- The surgical sequence can be customized and saved on the machine to save time. Turn the button to scroll through the menus and then validate your choice with a simple press. New intuitive control for simplified daily use and reduced treatment time.
Easy choice of surgical protocol and speed/torque settings in only 3-5 steps

- Patented irrigation systemAll our implantology systems incorporate a very practical peristaltic pump designed and patented by Bien-Air. Our irrigation lines include an insert holder that guarantees the easiest handling and optimal hygiene. Accessible and comfortable pump system. Adjustable flow rate from 30-150 ml/min. Safe and sterile: no contact between pump and liquid.

- Foot pedal To control the speed variation and the rotation of the surgical drill, switch the peristaltic pump and control the operating sequences. No need to touch the console during surgery.

- Simple, even during maintenanceThe control button can be easily removed from the console for sterilization. In addition, the control area is protected by an easy-to-clean, high-strength glass. The simplicity is also hidden in the details.
Removable and sterilizable wheel.

- RELIABLE HANDPIECE AND SURGICAL DRILL

Reliable and robust, withstands over 1500 cycles at 70 Ncm The smallest head on the market
Micro-Series: greater comfort with less strain on the handInternal irrigation system for greater user comfort, compatible with the Kirschner-Meyer irrigation system.

TECHNICAL DATA SHEET:

- Chiropro PLUS 3rd Gen

- Implantology mode

- Mode of surgery

- Control button (sterilizable)

- Max. torque on rotary instrument in implant mode 80 Ncm

- Dimensions (length x width x height) 240mm x 240mm x 102mm

- Weight 2.2 kg

- 2 to 3 year device warranty

- Specifications MX-i MX-i LED 1600755-001 With self-ventilation

- Surgical drill dimensions: ø x L 23 x 91mm

- Weight of the surgical drill 115g

PACK CONTENTS:

- 1 Chiropro Plus 3rd Gen Console

- 1 MX-i LED Plus third generation surgical drill, 3 year warranty

- 1 MX-i LED Plus third generation cable

- 1 foot pedal

- 1 handpiece holder

- 5 watering lines

- 2 sterile protective films

- 1 Trio Maintenance Pack
